Page 12
PhMKP..., PhMKPg..., Cylindrical, LVAC
www.vishay.com
Vishay ESTA
Revision: 09-Dec-11
11
Document Number: 13004
For technical questions, contact:
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
3-PHASE CAPACITORS IP00, DRY
Notes
• Other voltage ratings, outputs, and frequencies upon request. All PhMKP-type capacitors may be also be applied in 60 Hz networks, output
and current will, however, be 20 % higher in these cases (i.e. additional thermal load and therefore, a lower class of temperature must be
taken into account)
(1)
Version no. xx may differ as it respects small changes, e.g. on the label
Terminal cover (IP20), available for 84.4 mm diameter tubular can type capacitors.
(Cable gland not available for use with these covers)
Type CAP84-88-IN-LINE
• Protection class IP20
• Protective cover prevents unintentional touching of live terminals
• Proper ventilation is provided by use of additional holes in the protective cover’s top
• Six slots located on the cover, three on each side, allow easy IN-LINE connection between two
RATED VOLTAGE 660 V, 50 Hz, DELTA CONNECTION, UL/ULC UP TO 660 V
CAN BE USED ALSO FOR 690 V, FULL OVER VOLTAGE RANGE
TYPE
ARTICLE NO.
(1)
OUTPUT
kvar
660 V
OUTPUT
kvar
690 V
CAP.
μF
CURRENT
A
660 V/690 V
DIMENSIONS
Ø x H
mm
WEIGHT
kg
DRAWING
NO.
PhMKPg660.3.08,33-84
5343-44026-xx
8.33
9.1
3 x 20.3
7.3/7.6
84.4 x 190
0.9
2
PhMKPg660.3.10,00-84
5343-44027-xx
10
10.9
3 x 24.4
8.7/9.1
84.4 x 190
1.1
2
PhMKPg660.3.12,50-84
5343-44028-xx
12.5
13.7
3 x 30.4
10.9/11.5
84.4 x 265
1.2
2
PhMKPg660.3.15,00-84
5343-44029-xx
15
16.4
3 x 36.5
13.1/13.7
84.4 x 265
1.4
2
PhMKPg660.3.16,70-84
5343-44030-xx
16.7
18.3
3 x 40.7
14.6/15.3
84.4 x 265
1.5
2
PhMKPg660.3.20,00-84
5343-44031-xx
20
21.9
3 x 48.7
17.5/18.3
84.4 x 340
1.7
2
PhMKPg660.3.22,90-84
5343-44032-xx
22.9
25.0
3 x 55.8
20.0/20.9
84.4 x 340
1.9
2
RATED VOLTAGE 690 V, 50 Hz, DELTA CONNECTION
CAN BE USED ALSO FOR 660 V
TYPE
ARTICLE NO.
(1)
OUTPUT
kvar
660 V
OUTPUT
kvar
690 V
CAP.
μF
CURRENT
A
690 V/660 V
DIMENSIONS
Ø x H
mm
WEIGHT
kg
DRAWING
NO.
PhMKPg690.3.12,50-84
5343-44033-xx
11.4
12.5
3 x 27.9
10.5/10.0
84.4 x 265
1.1
2
PhMKPg690.3.15,00-84
5343-44034-xx
13.7
15
3 x 33.4
12.6/12.0
84.4 x 265
1.3
2
PhMKPg690.3.20,00-84
5343-44035-xx
18.3
20
3 x 44.6
16.7/16.0
84.4 x 340
1.6
2
PhMKPg690.3.25,00-84
5343-44036-xx
22.9
25
3 x 55.8
20.9/20.0
84.4 x 340
1.9
2
TYPE
ARTICLE NO.
CAPACITOR Ø IN mm
CAP84-88-IN-LINE
5341-COV-84-88-IP20-7
84.4
TERMINAL COVER IP20: CAP84-IN-LINE
IN-LINE CONNECTION BETWEEN TWO CAPACITORS, IP20
