www.vishay.com For technical questions, contact: [email protected] Document Number: 94358
2 Revision: 04-Jul-08
VSK.56..PbF/VSK.71..PbF Series
Vishay High Power Products Standard Diodes, 60/80 A
(ADD-A-PAK TM Generation 5 Power Modules)
ELECTRICAL SPECIFICATIONS
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT 150 °C
mA
VSK.56/.71
04 400 500
10
06 600 700
08 800 900
10 1000 1100
12 1200 1300
14 1400 1500
16 1600 1700
FORWARD CONDUCTION
PARAMETER SYMBOL TEST CONDITIONS VSK.56 VSK.71 UNITS
Maximum average forward current
at case temperature
I
F(AV)
180° conduction, half sine wave
60 80 A
100 100 °C
Maximum RMS forward current I
F(RMS)
DC at 92 °C case temperature 94 126
A Maximum peak, one-cycle forward,
non-repetitive surge current
I
FSM
t = 10 ms No voltage
reapplied
Sinusoidal half wave,
intitial T
J
= T
J
maximum
1600 1790
t = 8.3 ms 1680 1870
t = 10 ms 100 % V
RRM
reapplied
1350 1500
t = 8.3 ms 1420 1570
Maximum I 2 t for fusing I 2 t
t = 10 ms No voltage
reapplied 12.89 15.90
kA 2 s
t = 8.3 ms 11.76 14.53
t = 10 ms 100 % V
RRM
reapplied
9.12 11.25
t = 8.3 ms 8.32 10.23
Maximum I 2 √t for fusing I 2 √t t = 0.1 to 10 ms, no voltage reapplied 128.9 159.0 kA 2 √s
Low level value of threshold voltage V
F(TO)1
(16.7 % x π x I
F(AV)
< I < π x I
F(AV)
), T
J
= T
J
maximum 0.96 0.83
V
High level value of threshold voltage V
F(TO)2
(I > π x I
F(AV)
), T
J
= T
J
maximum 1.03 0.92
Low level value of forward
slope resistance
r
f1
(16.7 % x
π x I
F(AV)
< I <
π x I
F(AV)
), T
J
= T
J
maximum 2.81 2.68
m
Ω
High level value of forward
slope resistance
r
f2
(I > π x I
F(AV)
), T
J
= T
J
maximum 2.48 2.40
Maximum forward voltage drop V
FM
I
FM
=
π x I
F(AV)
, T
J
= 25 °C, t
p
= 400 µs square wave 1.51 1.50 V
BLOCKING
PARAMETER SYMBOL TEST CONDITIONS VSK.56 VSK.71 UNITS
Maximum peak reverse
leakage current
I
RRM
T
J
= 150 °C 10 mA
RMS insulation voltage V
INS
50 Hz, circuit to base, all terminals shorted 3500 (1 s) V
