GBPC
Outline Dimensions
Vishay Semiconductors
DIMENSIONS FOR GBPC...A in millimeters
DIMENSIONS FOR GBPC...W in millimeters
6.35 (4 x)
0.8
20
Ø 2.4
7.7
28.6
18.1
28.6 14.3
AC1
Ø 5.3 16.6
16.6
AC2
32/34
1.0 (4 x)
7.7
28.6
18.1
5.3
28.6 Ø 5.3
12.2 11.4
AC1
18.1
AC2
