GBPC.. Series
Vishay High Power Products Single Phase Bridge
(Power Modules), 25/35 A
ELECTRICAL SPECIFICATIONS
Note
(1) See Ordering Information table at the end of datasheet
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM
REPETITIVE PEAK AC
REVERSE VOLTAGE
T
J
= T
J
MAXIMUM
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK AC REVERSE VOLTAGE
T
J
= T
J
MAXIMUM
V
I
RRM
MAXIMUM AT
RATED V
RRM
T
J
= T
J
MAXIMUM
mA
I
RRM
MAXIMUM
DC REVERSE
CURRENT AT
T
J
= 125 °C
µA
GBPC25/35..A (1)
GBPC25/35..W
02 200 275
2 500
04 400 500
06 600 725
08 800 900
10 1000 1100
12 1200 1300
FORWARD CONDUCTION
PARAMETER SYMBOL TEST CONDITIONS GBPC25 GBPC35 UNITS
Maximum DC output current
at case temperature
I
O
Resistive or inductive load 25 35
A
Capacitive load 20 28
60 55 °C
Maximum peak, one-cycle
non-repetitive forward current
I
FSM
t = 10 ms No voltage
reapplied
Initial T
J
= T
J
maximum
400 475
A
t = 8.3 ms 420 500
t = 10 ms 100 % V
RRM
reapplied
335 400
t = 8.3 ms 350 420
Maximum I 2 t for fusing I 2 t
t = 10 ms No voltage
reapplied 790 1130
A 2 s
t = 8.3 ms 725 1030
t = 10 ms 100 % V
RRM
reapplied
560 800
t = 8.3 ms 512 730
Maximum I 2 √t for fusing
I 2 √t
I 2 t for time t
x
= I 2 √t x √t
x
; 0.1
≤ t
x
≤ 10 ms, V
RRM
= 0 V 7.9 11.3 kA 2 √s
Low level of threshold voltage V
F(TO)1
(16.7 % x
π x I
F(AV)
< I <
π x I
F(AV)
), T
J
maximum 0.76 0.77
V
High level of threshold voltage V
F(TO)2
(I >
π x I
F(AV)
), T
J
maximum 0.89 0.92
Low level forward slope resistance r
t1
(16.7 % x
π x I
F(AV)
< I <
π x I
F(AV)
), T
J
maximum 8.2 4.852
m
Ω
High level forward slope resistance r
t2
(I >
π x I
F(AV)
), T
J
maximum 6.8 3.867
Maximum forward voltage drop V
FM
T
J
= 25 °C, I
FM
= I
Favg (arm)
1.1 V
Maximum DC reverse current I
RRM
T
J
= 25 °C, per diode at V
RRM
5.0 µA
RMS isolation voltage base plate V
INS
f = 50 Hz, t = 1 s 2700 V
