Z300
Vishay Draloric
Axial Cemented Wirewound Resistors
FEATURES
• All welded construction
• Non flammable cement coating
• Ceramic core
• Various kinds of lead forming available
• Lead (Pb)-free
1) Lower TCR or other power range on request
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL HISTORICAL
MODEL
POWER RATING
P
40 °C
W
TOLERANCE
± %
RESISTANCE RANGE E12/E24 1)
Ω
WM 50 (Class 1)
TCR -10...-80 ppm/K
WM 110 (Class 3)
TCR 100...180 ppm/K
Z310309 Z301 1
10
5
2
1
R30 - 270R
R30 - 270R
-
-
R68 - 2K0
R68 - 2K0
-
-
ZDA0411 ZDA0411 2
10
5
2
1
R47 - 560R
R47 - 560R
on request
on request
1R5 - 4K3
1R5 - 4K3
-
-
ZDV0411 ZDV0411 2
10
5
2
1
R47 - 560R
R47 - 560R
on request
on request
1R5 - 4K3
1R5 - 4K3
-
-
Z320414 Z302 3
10
5
2
1
R10 - 510R
R10 - 510R
R22 - 510R
1R0 - 510R 1R8 - 3K3
24R - 3K3
-
-
Z330617 Z303 4
10
5
2
1
R10 - 1K0
R10 - 1K0
R10 - 1K0
1R0 - 1K0 1R8 - 3K9
12R - 3K9
-
-
Z350922 Z305 6
10
5
2
1
R10 - 2K4
R10 - 2K4
R62 - 2K4
R62 - 2K4 3R9 - 10K
10R - 10K
-
-
Z360933 Z306 8
10
5
2
1
R13 - 4K7
R13 - 4K7
1R0 - 4K7
2R2 - 4K7 6R8 - 16K
6R8 - 16K
-
-
Z370947 Z307 10
10
5
2
1
R20 - 8K2
R20 - 8K2
1R8 - 8K2
3R3 - 8K2 12R - 30K
12R - 30K
-
-
