Wirewound Resistors,
Industrial Power, Flat (HL), Miniature Flat (HLM)
HL, NHL FLAT and HLM, NHLM
Vishay Dale
www.vishay.com
For technical questions, contact: [email protected]
Document Number: 30209
72
Revision: 13-Jul-07
FEATURES
• High temperature silicon coating
• Mounting accommodations ideally suited to
high density packaging
• Self-stacking hardware for horizontal or vertical
placement
• Withstands high vibrations without loosening
• Mounting hardware functions as a heat sink
allowing greater heat dissipation and less
derating of stacked units
• Available in non-inductive styles (type NHL and NHLM)
with Aryton-Perry winding
* Pb containing terminations are not RoHS compliant, exemptions may apply
TYPE HL FLAT STYLE
Available
Pb-free
RoHS*
COMPLIANT
e3
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
HISTORICAL
MODEL
POWER RATING
P
25 °C
W
RESISTANCE RANGE
Ω
WEIGHT (typical)
g
± 5 %
± 10 %
HL024
NHL024
HL-24
NHL-24
30
1.0 - 11K
1.0 - 1.2K
0.10 - 11K
1.0 - 1.2K
20.14
HL035
NHL035
HL-35
NHL-35
40
1.0 - 26K
1.0 - 3K
0.10 - 26K
1.0 - 3K
30.07
HL055
NHL055
HL-55
NHL-55
55
1.0 - 54K
1.0 - 6.8K
0.10 - 54K
1.0 - 6.8K
51.25
HL070
NHL070
HL-70
NHL-70
70
1.0 - 77K
1.0 - 9.4K
0.10 - 77K
1.0 - 9.4K
60.48
HL095
NHL095
HL-95
NHL-95
95
1.0 - 99.9K
1.0 -12.4K
0.10 - 99.9K
1.0 - 12.4K
76.51
TYPE HLM MINIATURE FLAT STYLE
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
HISTORICAL
MODEL
POWER RATING
P
25 °C
W
RESISTANCE RANGE
Ω
WEIGHT (typical)
g
± 5 %
± 10 %
HLM010
NHLM010
HLM-10
NHLM-10
10
1.0 - 15K
1.0 - 1.8K
0.10 - 15K
1.0 - 1.8K
0.41
HLM015
NHLM015
HLM-15
NHLM-15
15
1.0 - 26K
1.0 - 3.6K
0.10 - 26K
1.0 - 3.6K
0.47
HLM020
NHLM020
HLM-20
NHLM-20
20
1.0 - 71K
1.0 - 9.8K
0.10 - 71K
1.0 - 9.8K
0.74
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: NHLM01010Z10R00JJ (preferred part number format)
GLOBAL
MODEL
TERMINAL
DESIGNATION
TERMINAL
FINISH
RESISTANCE
VALUE
TOLERANCE
PACKAGING CODE
SPECIAL
NHLM010
09
10
16
E = Lead
(Pb)-free
Z = Tin/lead
N = Nickel
R = Decimal
K = Thousand
10R00 = 10.0
Ω
1K000 = 1 k
Ω
J = ± 5.0 %
K = ± 10.0 %
E = Lead (Pb)-free skin pack
J* = Skin pack (J01)
(Dash Number)
(up to 2 digits)
From 1 - 99
as applicable
(See “Standard
Electrical
Specifications”
table above for
additional P/N’s)
* Tin/lead for type “Z”, lead (Pb)-free for type “N”
Historical Part Number Example: NHLM-10-10Z 10
Ω 5 % J01 (will continue to be accepted)
NHLM-10
10Z
10
Ω
5 %
J01
HISTORICAL MODEL
TERMINAL/FINISH
RESISTANCE VALUE
TOLERANCE
PACKAGING
H
L
M
0
1
0
1
0
Z
1
0
R
0
0
J
J
N
