Inverter Grade Thyristors
(Stud Version), 105 A
ST103SP Series
Vishay High Power Products
FEATURES
• All diffused design
• Center amplifying gate
• Guaranteed high dV/dt
• Guaranteed high dI/dt
• High surge current capability
• Low thermal impedance
• High speed performance
• Compression bonding
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Inverters
• Choppers
• Induction heating
• All types of force-commutated converters
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
105 A
TO-209AC (TO-94)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
105 A
T
C
85 °C
I
T(RMS)
165
A
I
TSM
50 Hz 3000
60 Hz 3150
I 2 t
50 Hz 45
kA 2 s
60 Hz 41
V
DRM
/V
RRM
400 to 800 V
t
q
Range 10 to 25 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM
REPETITIVE PEAK VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST103S
04 400 500
30
08 800 900
