Document Number: 94415

For technical questions, contact: [email protected]

www.vishay.com

Revision: 06-May-08

3

ST780CLPbF Series

Phase Control Thyristors

(Hockey PUK Version), 1350 A

Vishay High Power Products

Note
• The table above shows the increment of thermal resistance R

thJ-hs

when devices operate at different conduction angles than DC

TRIGGERING

PARAMETER SYMBOL

TEST

CONDITIONS

VALUES

UNITS

TYP.

MAX.

Maximum peak gate power

P

GM

T

J

= T

J

maximum, t

p

≤ 5 ms

10.0

W

Maximum average gate power

P

G(AV)

T

J

= T

J

maximum, f = 50 Hz, d% = 50

2.0

Maximum peak positive gate current

I

GM

T

J

= T

J

maximum, t

p

≤ 5 ms

3.0

A

Maximum peak positive gate voltage

+ V

GM

T

J

= T

J

maximum, t

p

≤ 5 ms

20

V

Maximum peak negative gate voltage

- V

GM

5.0

DC gate current required to trigger

I

GT

T

J

= - 40 °C

Maximum required gate
trigger/current/voltage are the
lowest value which will trigger
all units 12 V anode to cathode
applied

200

-

mA

T

J

= 25 °C

100

200

T

J

= 125 °C

50

-

DC gate voltage required to trigger

V

GT

T

J

= - 40 °C

2.5

-

V

T

J

= 25 °C

1.8

3.0

T

J

= 125 °C

1.1

-

DC gate current not to trigger

I

GD

T

J

= T

J

maximum

Maximum gate current/voltage
not to trigger is the maximum
value which will not trigger any
unit with rated V

DRM

anode to

cathode applied

10

mA

DC gate voltage not to trigger

V

GD

0.25

V

THERMAL AND MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL

TEST

CONDITIONS

VALUES

UNITS

Maximum operating junction temperature range

T

J

- 40 to 125

°C

Maximum storage temperature range

T

Stg

- 40 to 150

Maximum thermal resistance, junction to heatsink

R

thJ-hs

DC operation single side cooled

0.073

K/W

DC operation double side cooled

0.031

Maximum thermal resistance, case to heatsink

R

thC-hs

DC operation single side cooled

0.011

DC operation double side cooled

0.006

Mounting force, ± 10 %

14 700

(1500)

N

(kg)

Approximate weight

255

g

Case style

See dimensions - link at the end of datasheet

TO-200AC (B-PUK)

ΔR

thJ-hs

CONDUCTION

CONDUCTION ANGLE

SINUSOIDAL CONDUCTION

RECTANGULAR CONDUCTION

TEST CONDITIONS

UNITS

SINGLE SIDE

DOUBLE SIDE

SINGLE SIDE

DOUBLE SIDE

180°

0.009

0.009

0.006

0.006

T

J

= T

J

maximum

K/W

120°

0.011

0.011

0.011

0.011

90°

0.014

0.014

0.015

0.015

60°

0.020

0.020

0.021

0.021

30°

0.036

0.036

0.036

0.036
