Phase Control Thyristors
(Hockey PUK Version), 1350 A
ST780CLPbF Series
Vishay High Power Products
FEATURES
• Center amplifying gate
• Metal case with ceramic insulator
• International standard case TO-200AC (B-PUK)
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
1350 A
TO-200AC (B-PUK)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
1350 A
T
hs
55 °C
I
T(RMS)
2700 A
T
hs
25 °C
I
TSM
50 Hz 24 400
A
60 Hz 25 600
I 2 t
50 Hz 2986
kA 2 s
60 Hz 2726
V
DRM
/V
RRM
400 to 600 V
t
q
Typical 150 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM REPETITIVE PEAK
AND OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST780C..L
04 400 500
80
06 600 700
