PM25RSB120
Intellimod™ Module
Three Phase + Brake IGBT Inverter Output
25 Amperes/1200 Volts

596

Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272

Electrical and Mechanical Characteristics,

T

j

= 25

°

C unless otherwise specified

Characteristics

Symbol

Test Conditions

Min.

Typ.

Max.

Units

IGBT Inverter Sector

Collector Cutoff Current

I

CES

V

CE

= V

CES

, T

j

= 25

°

C

1.0

mA

V

CE

= V

CES

, T

j

= 125

°

C

10

mA

Diode Forward Voltage

V

FM

-I

C

= 25A, V

D

= 15V, V

CIN

= 5V

2.5

3.5

Volts

Collector-Emitter Saturation Voltage

V

CE(sat)

V

D

= 15V, V

CIN

= 0V, I

C

= 25A

2.5

3.5

Volts

V

D

= 15V, V

CIN

= 0V, I

C

= 25A,

2.2

3.2

Volts

T

j

= 125

°

C

Inductive Load Switching Times

t

on

0.5

1.0

2.5

µ

S

t

rr

V

D

= 15V, V

CIN

= 0 ~ 15V

0.15

0.3

µ

S

t

C(on)

V

CC

= 600V, I

C

= 25A

0.4

1.0

µ

S

t

off

T

j

= 125

°

C

2.0

3.0

µ

S

t

C(off)

0.7

1.2

µ

S

Brake Sector

Collector-Emitter Saturation Voltage

V

CE(sat)

V

D

= 15V, V

CIN

= 0V, I

C

= 25A,

2.8

3.8

Volts

T

j

= 25

°

C

V

D

= 15V, V

CIN

= 0V, I

C

= 25A,

2.5

3.5

Volts

T

j

= 125

°

C

Diode Forward Voltage

V

FM

-I

C

= 10A, V

D

= 15V, V

CIN

= 5V

2.5

3.5

Volts

Collector Cutoff Current

I

CES

V

CE

= V

CES

, T

j

= 25

°

C

1

mA

V

CE

= V

CES

, T

j

= 125

°

C

10

mA
