Intellimod™ Module

Three Phase + Brake
IGBT Inverter Output
25 Amperes/1200 Volts

PM25RSB120

593

Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20 KHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.

Features:

Complete Output Power
Circuit

Gate Drive Circuit

Protection Logic
– Short Circuit
– Over Current
– Over Temperature
– Under Voltage

Applications:

Inverters

UPS

Motion/Servo Control

Power Supplies

Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM25RSB120 is a 1200V,
25 Ampere Intellimod™ Intelligent
Power Module.

Type

Current Rating

V

CES

Amperes

Volts (x 10)

PM

25

120

Dimensions

Inches

Millimeters

A

3.96

±

0.04

100.5

±

1.0

B

3.48

±

0.02

88.5

±

0.5

C

2.76

±

0.04

70.0

±

1.0

D

2.30

±

0.02

58.5

±

0.5

E

1.191

±

0.02

30.25

±

0.5

F

0.83

21.0

G

0.75

19.0

H

0.73

18.5

J

0.71

18.0

K

0.69

17.5

L

0.67

17.0

M

0.581

14.76

N

0.541

13.75

P

0.541

13.74

Dimensions

Inches

Millimeters

Q

0.41

10.5

R

0.39

10.0

S

0.394

±

0.010 10.00

±

0.25

T

0.39 Dia.

Dia. 10.0

U

0.364

9.25

V

0.24

6.0

W

0.18 Dia.

Dia. 4.5

X

0.16

4.0

Y

0.12

3.0

Z

0.88

±

0.02

2.25

±

0.5

AA

0.086

±

0.02

2.18

±

0.5

AB

0.079

±

0.010

2.00

±

0.25

AC

0.06

1.5

AD

0.01

0.25

Outline Drawing and Circuit Diagram
