Document Number: 93755 For technical questions, contact: [email protected] www.vishay.com
Revision: 05-Nov-09 1
Passivated Assembled Circuit Elements, 40 A
P400 Series
Vishay High Power Products
FEATURES
• Glass passivated junctions for greater reliability
• Electrically isolated base plate
• Available up to 1200 V
RRM
/V
DRM
• High dynamic characteristics
• Wide choice of circuit configurations
• Simplified mechanical design and assembly
• UL E78996 approved
• Compliant to RoHS directive 2002/95/EC
DESCRIPTION
The P400 series of integrated power circuits consists of
power thyristors and power diodes configured in a single
package. With its isolating base plate, mechanical designs
are greatly simplified giving advantages of cost reduction
and reduced size.
Applications include power supplies, control circuits and
battery chargers.
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
O
40 A
PACE-PAK (D-19)
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL CHARACTERISTICS VALUES UNITS
I
O
80 °C 40 A
I
TSM
,
I
FSM
50 Hz 385
A
60 Hz 400
I 2 t
50 Hz 745
A 2 s
60 Hz 680
I 2 √t 7450 A 2 √s
V
RRM
Range 400 to 1200 V
V
ISOL
2500 V
T
J
- 40 to 125 °C
T
Stg
VOLTAGE RATINGS
TYPE
NUMBER
V
RRM
/V
DRM
, MAXIMUM
REPETITIVE PEAK REVERSE AND
PEAK OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK
REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
MAXIMUM
mA
P401, P421, P431 400 500
10
P402, P422, P432 600 700
P403, P423, P433 800 900
P404, P424, P434 1000 1100
P405, P425, P435 1200 1300
