Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
POW-R-BLOK
TM
http://www.pwrx.com
Dual Diode Isolated Module
600 Amperes / Up to 2600 Volts
Revision Date: 01/14/2010
LD41__60
Absolute Maximum Ratings
Characteristics Conditions
Symbol
Units
Repetitive Peak Reverse Blocking Voltage
V
RRM
up to 2600
V
Non-Repetitive Peak Reverse Blocking Voltage
(t < 5 msec)
V
RSM
V
RRM
+ 100
V
RMS Forward Current
I
F(RMS)
950 A
Average Forward Current
180° Conduction, T
C
=106°C I
F(AV)
600 A
Peak One Cycle Surge Current, Non-Repetitive
60 Hz, 100% V
RRM
reapplied
50 Hz, 100% V
RRM
reapplied
I
FSM
I
FSM
21000
19000
A
A
Peak Three Cycle Surge Current, Non-Repetitive
60 Hz, 100%V
RRM
reapplied
I
FSM
15,500 A
Peak Ten Cycle Surge Current, Non-Repetitive
60 Hz, 100% V
RRM
reapplied
I
FSM
13,000
A
I
2
t for Fusing for One Cycle
8.3 milliseconds
10 milliseconds
I
2
t
I
2
t
1,840,000
1,810,000
A
2
sec
A
2
sec
Operating Temperature
T
J
-40 to +150
°C
Storage Temperature
T
stg
-40 to +150
°C
Max. Mounting Torque, M6 Mounting Screw
55
6
in. – Lb.
Nm
Max. Mounting Torque, M10 Terminal Screw
110
12
in. – Lb.
Nm
Module Weight, Typical
1500
g
3.30
lb
V Isolation @ 25C
V
rms
3000 V
