VS230DM16CCB
Vishay High Power Products Standard Recovery Diodes
ORDERING INFORMATION TABLE
Device code
1 - Vishay HPP device
2 - Chip dimension in mils
3 - Type of device: D = Wire bondable standard recovery diode
4 - Passivation process: M = Glassivated MOAT
5 - Voltage code x 100 = V
RRM
6 - Metallization: C = Aluminum (anode) - silver (cathode)
7 - CB = Probed uncut die (wafer in box)
None = Probed die in chip carrier
5 1 3 2 4 6 7
VS 230 D M 16 C CB
LINKS TO RELATED DOCUMENTS
Dimensions http://www.vishay.com/doc?95125
