T9KC__0603
Phase Control Thyristor
Powerex, Inc., 173 Pavilion Ln, Youngwood, PA 15697-1800 (724)925-7272 WWW.PWRX.COM 600 Amperes 6500 Volts
0.0
2.0
4.0
6.0
8.0
10.0
100 1000 10000
VT
M (V)
ITM (A)
Maximum On-State Voltage Drop
Tj = 125°C
0.0E+00
5.0E-03
1.0E-02
1.5E-02
2.0E-02
2.5E-02
0.001 0.01 0.1 1 10
T
h
ermal Impedance (°C/W
a
tt)
Time (sec)
MAXIMUM TRANSIENT THERMAL IMPEDANCE
Page 4
