T9S0__
Phase Control Thyristor
Powerex, Inc., 173 Pavilion Ln, Youngwood, Pennsylvania 15697-1800 (724)925-7272 www.pwrx.com 2000 Amperes 1800 Volts
Absolute Maximum Ratings
Characteristic Symbol Rating Units
Repetitive Peak Voltage V
DRM
-V
RRM
1800 Volts
Average On-State Current, T
C
=72°C I
T(Avg.)
2000 A
RMS On-State Current, T
C
=72°C I
T(RMS)
3142 A
Average On-State Current, T
C
=55°C I
T(Avg.)
2200 A
RMS On-State Current, T
C
=55°C I
T(RMS)
3456 A
Peak One Cycle Surge Current, 60Hz, V
R
=0V I
TSM
27,000 A
Peak One Cycle Surge Current, 50Hz, V
R
=0V I
TSM
25,456 A
Fuse Coordination I 2 t, 60Hz I 2 t 3.04E+06 A 2 s
Fuse Coordination I 2 t, 50Hz I 2 t 3.24E+06 A 2 s
Critical Rate-of-Rise of On-State Current di/dt 100 A/us
Repetitive
Critical Rate-of-Rise of On-State Current di/dt 200 A/us
Non-Repetitive
Critical Rate-of-Rise of Off-State Voltage dv/dt 1000 V/us
VD = ⅔• VDRM
P k G t P 100 P 16 W tt Peak Gate Power, 100us P
GM
16 Watts
Average Gate Power P
G(avg)
5 Watts
Operating Temperature Tj -20 to+125 °C
Storage Temperature T
Stg.
-50 to+150 °C
Approximate Weight 0.65 lb
0.29 Kg
Mounting Force 5500-6000 lbs
24.5 - 26.7 Knewtons
Information presented is based upon limited testing or projected
capabilities. This information is subject to change without notice. The
manufacturer makes no claim as to suitability for use, reliability, capability
or future availability of this product.
