11 Supplement
POINTRAC 31 • Foundation Fieldbus
41779-EN-131119
FF descriptor Rel. In-
dex
Description Unit
NAMUR_STATE 49 NAMUR state -
NULL_COUNT_RATE 50 Zero count rate -
COUNT_RATE_PMT 51 Pulse rate photomultiplier (raw values) -
ADJ_DENSITY_ABS_
COEFF
52 Process absorption coefficient -
DEV_SW_VER_ASCII 53 Software version -
POINT_LEVEL_AD-
JUST_MODE
54 Point level adjustment mode -
RELAY_VALUE_SEL 55 Relay basic value -
DIGITAL_IN 56 Frequency of digital input -
DIGITAL_IN_BOOL 57 State of digital input -
ANALOG_IN 58 Current on analog input -
FF_CHANNEL_AVAIL-
ABLE
59 Available channels -
FF_CHANNEL_USED 60 Used channels -
Mapping of Process Value Status
Hex Quality Sub-Status Condition
0x00 Bad Non-specific Unexpected error
0x01 Bad Configuration Error It was tried to set a wrong unit with FF interface
On user error codes: 16, 17, 25, 52, 57, 66, 72,
117, 120
0x0C Bad Device Failure Five or more internal communications have failed
while "Process Data Update". Last usable value is
displayed
On user error codes: 8, 34, 35, 36, 37, 38, 73, 80,
86, 121, 122, 141
0x10 Bad Sensor Failure On user error codes: 40, 41, 53, 68, 123, 124, 125
0x1C Bad Out of Service Transducer block is in mode "Out of Service"
Channel is not assigned to an AIFB
Channel is not available in running application
0x20 Bad Transducer in MAN Transducer block is in mode "Manual"
0x44 Uncertain Last Usable Value Three or more internal communications have failed
while "Process Data Update". Last usable value is
displayed
0x48 Uncertain Substitute On user error codes: 29
0x4C Uncertain Initial Value After startup of device or channel assignment in
AIFB was changed. The channel unit may be un-
known until next "Process Data Update"
On user error codes: 13
0x80 Good (NC) Non-specific No errors concerning to channel handling
On user error codes: 0, 33, 45, 71, 126, 127
