3 supplement, 1 technical data, 3supplement – VEGA KV 31 Mounting brackets For tubes with ø 50…100 mm User Manual
Page 13
3
Supplement
3
.1 Technical data
General data
Take note of the information in the operating instructions manual of the installed MINITRAC level
sensor and the source holder
Material 316L corresponds to 1.4404 or 1.4435
Materials
-
Mounting brackets
316L
-
Threaded rods
316L
Weight (without sensor and source holder)
-
Mounting bracket - without colli-
mator
47.6 kg (105 lbs)
-
Mounting bracket - with collimator
sensor side
57.8 kg (127.4 lbs)
-
Mounting bracket - with collimator
radiator side
58.4 kg (128.8 lbs)
-
Mounting bracket - with collimator
both sides
68.6 kg (151.3 lbs)
Torques
-
Screws - Sensor mounting (M8)
15 Nm (11.06 lbf ft)
-
Nuts - VEGASOURCE (M16)
20 Nm (14.75 lbf ft)
-
Threaded rods (M10)
Dependent on the tube material
Mounting brackets KV 31 • Source holder SE
13
3 Supplement
41863
-
EN
-120228
