11 Supplement
VEGABAR 83 • Profibus PA
45037-EN-131107
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
Gauge pressure
0 … +0.15 psig
+225 psig
0 … +5 psig +375 psig -11.60 psig
0 … +15 psig +525 psig -14.5 psig
0 … +30 psig +600 psig -14.5 psig
0 … +150 psig +1350 psig -14.5 psig
0 … +300 psig +1500 psig -14.5 psig
-14.5 … 0 psig +500 psig -14.5 psig
-14.5 … +20 psig +580 psig -14.5 psig
-14.5 … +150 psig +1480 psig -14.5 psig
-14.5 … +300 psig +1575 psig -14.5 psig
-0.7 … +0.7 psig +225 psig -14.5 psig
-3 … +3 psig +290 psi -14.5 psig
-7 … +7 psig +510 psig -14.5 psig
Absolute pressure
0 … 1.5 psi
225 psi 0 psi
0 … 5 psi 435 psi 0 psi
0 … 15 psi 510 psi 0 psi
0 … 30 psi 725 psi 0 psi
0 … 150 psi 1300 psi 0 psi
0 … 300 psi 1900 psi 0 psi
Output variable
Output signal
digital output signal, format according to IEEE-754
Sensor address 126 (default setting)
Damping (63 % of the input variable) 0 … 999 s, adjustable
Profibus PA profile 3.02
Number of FBs with AI (function blocks
with analogue input)
3
Default values
Ʋ 1. FB PV
Ʋ 2. FB SV 1
Ʋ 3. FB SV 2
Current value
Ʋ Non-Ex and Ex ia instrument 10 mA, ±0.5 mA
Ʋ Ex-d instruments 16 mA, ±0.5 mA
Resolution, digital < 1 mm (0.039 in)
