This function enables reading out parameter adjustment data as well
as writing parameter adjustment data into the sensor via the indicating
and adjustment module. A description of the function is available in the
operating instructions manual "Indicating and adjustment module".
The following data are read out or written with this function:
l Measured value presentation
l Adjustment
l Medium
l Vessel form
l Damping
l Linearisation curve
l Sensor-TAG
l Displayed value
l Unit of measurement
l Language
l Sensitivity
l PA scaling unit
l PV-Out-Scale
l Channel
l Additional PA value
l Dielectric figure
The following safety-relevant data are not read out or written:
l HART mode
l PIN
l Sensor length/Sensor type
l False signal suppression
Copy sensor data
Copy sensor data?
Basic adjustment
If the function "Reset" is carried out, the sensor resets the values of the
following menu items to the reset values (see chart):
2)
The following values will be reset:
Function Reset value
Max. adjustment Distance, upper dead zone
Min. adjustment Distance, supplied sensor length
Min. adjustment - Cable version Distance, lower dead zone
Damping ti 0 s
Linearisation Linear
Sensor-TAG Sensor
2) Sensor-specific basic adjustment.
Copy sensor data
Reset
