T
wo-wire electronics 4 … 20 mA/HART for power supply and
measured value transmission over the same cable.
T he supply voltage range can differ depending on the instrument
version.
T he data for power supply are specified in chapter "Technical data".
T he background lighting of the indicating and adjustment module is
powered by the sensor. Prerequiste is a certain heigt of the operating
voltage. You can find the exact voltage specifications in chapter
"T
echnical data".
T
he optional heating requires its own operating voltage. You can find
details in the supplementary instructions manual "Heating for indicat-
ing and adjustment module".
T
his function is generally not available for approved instruments.
3.3 Operation
VEGABAR 63 can be adjusted with different adjustment media:
l
with indicating and adjustment module
l
with the suitable VEGA DTM in conjunction with an adjustment
software according to the FDT/DTM standard, e.g. PACTware and
PC
l
with manufacturer-specific adjustment programs AMS™ or PDM
l W ith a HART handheld
T he entered parameters are generally saved in VEGABAR 63,
optionally also in the indicating and adjustment module or in
PACT
ware.
3.4 Packaging, transport and storage
Y our instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
T he packaging of standard instruments consists of environment-
friendly, recyclable cardboard. For special versions, PE foam or PE foil
is also used. Dispose of the packaging material via specialised
recycling companies.
I nstruments for oxygen applications are sealed in PE foil and provided
with a label "Oxygen! Use no Oil". Remove this foil just before
mounting the instrument! See instruction under "Mounting".
T ransport must be carried out under consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
Power supply
Packaging
Transport
