10 Supplement
VEGACAL 67 • Foundation Fieldbus
31760-EN-130917
Connection cable
Ʋ Wire cross-section 0.5 mm² (AWG 20)
Ʋ Wire resistance < 0.036 Ω/m (0.011 Ω/ft)
Ʋ Tensile strength < 1200 N (270 lbf)
Ʋ Standard length 5 m (16.4 ft)
Ʋ Max. length 1000 m (3280 ft)
Ʋ Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F)
Ʋ Diameter approx. 8 mm (0.315 in)
Ʋ Colour - standard PE Black
Ʋ Colour - standard PUR Blue
Ʋ Colour - Ex-version Blue
Display and adjustment module
Voltage supply and data transmission
through the sensor
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection rating
Ʋ unassembled IP 20
Ʋ mounted into the sensor without cover IP 40
Material
Ʋ Housing ABS
Ʋ Inspection window Polyester foil
Voltage supply
Operating voltage
Ʋ Non-Ex instrument 9 … 32 V DC
Ʋ Ex-ia instrument 9 … 24 V DC
Ʋ Ex-d instrument 16 … 32 V DC
Operating voltage with illuminated display and adjustment module
Ʋ Non-Ex instrument 12 … 32 V DC
Ʋ Ex-ia instrument 12 … 24 V DC
Ʋ Ex-d instrument 20 … 32 V DC
Power supply by/max. number of sensors
Ʋ Fieldbus max. 32 (max. 10 with Ex)
Electrical protective measures
Protection, depending on housing version
Ʋ Plastic housing IP 66/IP 67
Ʋ Aluminium housing, stainless steel
housing - investment casting, stain-
less steel housing - electro-polished
IP 66/IP 68 (0.2 bar) 4)
4) A suitable cable is the prerequisite for maintaining the protection rating.
