Function Reset value
Vessel form not known
Damping 0 s
Linearisation linear
Channel PV lin. %
Sensor-TAG Sensor
Displayed value PA-Out
Extended settings None
Additional PA value Secondary Value 1 %
Out-Scale-Unit %
PV-Out-Scale 0.00 lin-% = 0.0 %
100.0 lin-% = 100 %
Unit of measurement m(d)
The values of the following menu items are not reset to the reset
values (see chart) with "Reset":
Function Reset value
Sensor address no reset
Language no reset
Factory setting
Like basic adjustment, furthermore special parameters are reset to
default values.
6)
Pointer
The min. and max. distance values are reset to the actual value.
Additional adjustment and diagnosis options such as e.g. scaling,
simulation or trend curve presentation are shown in the following menu
schematic. You will find a detailed description of these menu items in
the operating instructions manual "Indicating and adjustment module".
6) Special parameters are parameters which are set customer-specifically on
the service level with the adjustment software PACTware.
Optional settings
VEGAPULS 66 standpipe version • Profibus PA 33
