Product description
3
.1 Structure
The scope of delivery encompasses:
l
Digital indicating instrument VEGADIS 175
l
Documentation
-
this operating instructions manual
-
Ex specific safety instructions (with Ex versions), if necessary
further certificates
3
.2 Principle of operation
VEGADIS
175 is a digital indicating instrument for measured value
indication in 4 … 20 mA circuits. The measured value is displayed via
the LC display, the digital indication can be scaled. The instrument is
suitabe for front panel mounting.
VEGADIS
175 is looped directly into the 4 … 20 mA circuits and
requires no separate external energy. Connection is carried out via
screw terminals in the housing.
3
.3 Operation
Adjustment is carried out via keys in the front plate of the instrument.
3
.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
The packaging of standard instruments consists of environment-
friendly, recyclable cardboard. For special versions, PE foam or PE foil
is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out under consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or
concealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Scope of delivery
Application area
Voltage supply
Packaging
Transport
Transport inspection
Storage
