1 Push the "OK" key longer than three seconds to get to the
adjustment menu. The display shows again: "dI dP"
2 Push the "OK" key briefly twice to reach the menu item "dI Hi"
3 Set the requested indication value for 20 mA with the "+/–" keys
4 Accept or discard like with indication value 0 %
The adjustment of the indication value 100 % is finished. The actual
measured value is then displayed.
1 Push the "OK" key longer than three seconds to get to the
adjustment menu. The display shows again: "dI dP"
2 Push the "OK" key briefly three times to reach the menu item
"
oFFST"
3 Set the requested offset value with the "+/–" keys
4 Accept or discard like with indication value 0 %
The parameter adjustment of the offset is finished. The actual
measured value is then displayed.
Tip:
The previously described menu items can also be completed one after
the other and saved all at once. Press the "OK" key only very briefly
after the parameter adjustment of a menu item. By doing this, you
reach the next menu item for which you can carry out the parameter
adjustment as described above.
6 .3 Operation
Adjustment or process errors are immediately signalled in the display.
Messages to be acknowledged are immediately deleted after key
pressing.
Indication Cause Rectification
"∏∏∏∏" Measuring range underrun.
There is an input signal
≤
3.6 mA on the analogue
input.
Check input signal
"UUUU" Measuring range exceeded.
There is an input signal ≥ 21 mA
on the analogue input. Check input signal
"SA UE ?" Adjustment parameters were
modified. The instrument asks
for release to save. Release or unrelease with the
"+/–" keys and save with the
"OK"
key or discard.
"SA UE ?" fla-
shing
After a change of the adjust-
ment parameters, the instru-
ment saves them in the
EEPROM. After saving, the instrument
displays the measured value.
Indication value 100 %
Offset
System messages
