9 Supplement
9 .1 Technical data
General data
Materials
-
Housing front Aluminium die-casting
-
Housing Sheet steel galvanized
-
Rear of the housing plastic ABS
-
Inspection window of the indication
Installation position no limitations
Weight approx. 0.3 kg (0.661 lbs)
Ambient conditions
Ambient temperature -10 … +60 °C (14 … +140 °F)
Storage and transport temperature -25 … +70 °C (-13 … +158 °F)
Climatic class Class B 2 according to EN 60 654-1
Electromechanical data
Screw terminals for cable cross-section up to
-
massive 1.5 mm² (AWG 15)
-
Stranded wire with end sleeve 1.0 mm² (AWG 18)
Indicating and adjustment elements
Indication LC display, 5-digit
Height of figures 17 mm
Indication range -199999 up to +999999
Adjustment elements 3 keys (-/+/E)
Circuit
Range 4 … 20 mA
Input current max. 150 mA
HART signal is transmitted
Voltage supply
Operating voltage via 4 … 20 mA current
loop 12 … 36 V DC
Voltage loss 2 V
Load see diagram in the operating instructions manual of
the respective sensor
