Technical data
6 Technical data
6.1 Technical data
Power supply
Supply voltage 9 … 32 V DC)
(output voltage U
O
of the segment (depending on segment coupler used)
coupler) see PA specification, e.g.
- non-Ex 22 V DC (nominal voltage of the segment
coupler) max. 32 sensors on one two-wire
cable
- Ex 13.5 V DC (nominal voltage of the segment
coupler) max. 10 sensors on one two-wire
cable (typically 8 sensors)
Current consumption constantly 10 mA (no leakage current output)
Load depending on segment coupler, see
technical data of the segment couplers and
Profibus specification
Measuring range
VEGAFLEX 55 0.1 ... 4 m
Output signal
digital (Profibus) Two-wire technology:
The digital output signal (measuring signal) is
modulated onto the power supply and further
processed in the PLC or process control room .
Integration time 0 … 999 seconds (adjustable)
Adjustment
- adjustment software VEGA Visual Operating on Master-Class 2 PC
- adjustment module MINICOM in the sensor or in the external instrument (optional)
- process adjustment interface PACTware
TM (under which VVO runs as a subprogram)
- SIMATIC PDM in conjunction with Electronic Device Description (EDD)
Accuracy 1)
(under reference conditions acc. to IEC 770 - relating to the max. measuring range)
Linearity error < 0.1 %
Temperature drift 0.015 %/10 K
Characteristics linear
Deviation in characteristics incl.
linearity, reproducibility and
hysteresis (limit point method)
better than 0.05 %
Average temperature coefficient of the
zero signal
0.06 %/10 K
General resolution max. 1 mm
Resolution of the output signal 0.005 % or 1 mm
1) ISimilar to DIN 16 086, reference conditions acc. to IEC 770, e.g.
temperature 15°C … 35°C; moisture 45 % … 75 %; pressure 860 mbar … 1060 mbar
