VEGAFLEX 55P (Profibus PA) 37
Function diagram and PA parameters
Out Scale
- primary value (%,m,ft ...)
- secondary value 1 (%,m,ft ...)
- secondary value 2 (m,ft ...)
(dep. on channel)
Scaling (PV-Scale and Out-Scale)
4 0
EU
10%
EU
100%
Out Scale
1
0
EU 0% EU 100%
PV Scale
Device status
Fail safe
Fail safe value [out scale unit]
Fail safe type eq:
- OFF,
- Last valid Out,
- As calculated
Actual mode
Target mode
Mode & Status calc.
Man
Auto
Mode
Fail safe value
Fail safe
Scaled (PA-Out)
[output signal
see Kap 3.3]
PDM
VVO
FDT
MINICOM
PDM
VVO
FDT
PDM
VVO
FDT
Function-Block
E
B
D
out
PV Scale
- primary value (%,m,ft ...)
- secondary value 1 (%,m,ft ...)
- secondary value 2 (m,ft ...)
(dep. on channel)
