VEGA VEGATROL 10 Ex 1 User Manual
Vegatrol 10 ex 1
TIB • Technical Information • Operating Instructions
VEGATROL 10 Ex 1
Fail safe overfill
protection for
pressurized vessels
storing liquid gas
VEGA Grieshaber KG
Postfach 11 42
D-77757 Schiltach
Phone 0 78 36 / 50 - 0
Fax 0 78 36 / 50 201
VEGATOR 526W Ex
on
Approved acc. to the
VdTÜV-information
"Overfill protection" 100
no. TÜV.ÜS.94-32
liquid gas PN 25
Corresponds to the
requirements to
component tested overfill
protections of TRB 801,
no. 25
Corresponds to the
requirements of
DIN V 19250 AK 5
Conformity certificates
PTB-no. Ex-93.C.4015
BVS-no. 93.C.2015 X
