VEGATOR 537 Ex 3
23465-EN-030723
Product description
1 Product description
1.1 Configuration
A measuring system with signal conditioning
instrument consists of:
- a VEGAVIB series 50 with oscillator
VIB E50 Z (Ex)
- a VEGATOR 537 Ex signal conditioning
instrument
- external devices operated by VEGATOR
or
- a VEGASWING series 60 or 80A with oscil-
lator SW E60ZEx, SW E82Z or SW E82ZEx
- a VEGATOR 537 Ex signal conditioning
instrument
- external devices operated by VEGATOR
1.2 Technical data
General
Series module unit for carrier BGT 596 Ex
Dimensions W = 25.4 mm (5 TE), H = 128.4 mm, D = 162 mm
Weight approx. 180 g
Test key (per channel) for function test
Ambient conditions
Ambient temperature -20°C … +60°C
Storage and transport temperature -40°C … +70°C
Power supply
Operating voltage 20 … 53 V AC, 20 … 72 V DC
Power consumption max. 3 W
Electrical connection multiple plug DIN 41 612,
series F (d, b, z) 33-pole
Electrical protective measures
Protection class II
Overvoltage category II
Protection
- mounted into housing type 505 Ex
IP 30
Protection
(mounted into carrier
BGT 596 Ex with Ex module)
- front side (completely equipped)
IP 30
- upper and lower side IP 20
- wiring side IP 00
