6 VEGASWING 81A EXD and 83A EXD
Product description
1.3 Technical data
VEGASWING 81A EXD and 83A EXD
Housing
Housing material Aluminium (plastic coated)
Protection IP 66 and IP 67 (meets both protections)
Cable entry 1 /
2
“ NPT EExd
Terminals max. 1 x 1,5 mm 2 cross-section area of
conductor
Mechanical connection
Thread G 1 A or 1“ NPT
- material 1.4571 (stst) or Hastelloy C4
Flanges DIN and ANSI from DN 32
- material 1.4571, 1.4571 with Hastelloy C4 plated
DN 50 PN 40 enamelled steel
or 1.4571 ECTFE-coated
Hygienic fittings
Material
1.4571 (stst)
- conus DN 25
- bolting DN 40, DN 50
- TRI-Clamp 1 1 /
2
“, 2“
- Tuchenhagen Varivent DN 50 PN 10
- hyg. connection with compression nut F40 PN 25, 14571, 14581
- hyg. connection with tension flange DN 32 PN 25, 1.4571, 1.4581
Tuning fork
Material 1.4581, Hastelloy C4, Hastelloy C4 enamelled
1.4581, with ECTFE coated
Extension tube (VEGASWING 83A EXD)
Material 1.4571, Hastelloy C4, Hastelloy C4 enamelled
1.4571 with ECTFE coated
Length
- 1.4571, Hastelloy C4
180 mm … 4000 mm
- Hastelloy C4 enamelled 180 mm … 1200 mm
- 1.4571, ECTFE (Halar) 180 mm … 1600 mm
Weight
Basic weight approx. 2,5 kg
Tube extension approx. 0,11 kg/m
