Wiha Info
Wiha ErgoStar
The right idea:
a flowing movement means all L-keys
are ready for removal.
120
369R Zoll Ball end hex L-key, long.
With MagicRing ® . Inch sizes.
Blade: Chrome-vanadium steel, through hardened, chrome-plated.
Standards: Based on ASME B18.3.
Application: Insert hex inch screws into and remove from boreholes,
especially in difficult to access areas.
Extra: MagicRing ® made from spring steel holds all standard screws
tight at various angles (available from 1/8").
The ball end enables the user to work at angles up to 25°.
For Allen screws (inch).
Order-No.
29471 0.05 72 13 1.27 10
29472 1/16 80 15 1.59 10
29474 5/64 88 18 1.98 10
29473 3/32 101 20 2.38 10
29475 7/64 111 21 2.78 10
24302 1/8 121 23 3.17 10
24304 9/64 136 27 3.57 10
24303 5/32 148 29 3.96 10
24305 3/16 163 33 4.76 10
24306 7/32 176 36 5.55 10
24307 1/4 191 38 6.35 10
24308 5/16 210 43 7.93 10
24341 3/8 232 50 9.52 10
For Allen screws (inch).
369R HZ13 Hexagon ball end L-key set in ErgoStar holder.
From size 1/8" with MagicRing, chrome-plated, 13 pc. inch design.
Blade: Chrome-vanadium steel, through hardened, chrome-plated.
Standards: Based on ASME B18.3.
Application: Insert hex inch screws into and remove from boreholes,
especially in difficult to access areas.
Extra: Mechanical operation of the space-saving ErgoStar holder
makes simplest removal of each individual L-key possible
without movement of the others.
MagicRing ® made from spring steel holds all standard screws
tight at various angles (available from 1/8").
The ball end enables the user to work at angles up to 25°.
Order-No.
36521 369R HZ13 5
369 Zoll C 0.05 1/16 5/64 3/32 7/64
369R Zoll 1/8 9/64 5/32 3/16 7/32
1/4 5/16 3/8
SB 369R HZ13 Hexagon ball end L-key set in ErgoStar holder.
From size 1/8" with MagicRing, chrome-plated, 13 pc. inch design.
In blister pack.
Order-No.
36522 SB 369R HZ13 5
369R SZ13 Ball end hex L-key set in ProStar.
With MagicRing ® , chrome-plated, 13 pcs. Inch sizes.
Blade: Chrome-vanadium steel, through hardened, chrome-plated.
Standards: Based on ASME B18.3.
Application: Insert hex inch screws into and remove from boreholes,
especially in difficult to access areas.
Extra: Space saving ProStar allows the easy removal of each key
without moving any others.
MagicRing ® made from spring steel holds all standard screws
tight at various angles (available from 1/8").
The ball end enables the user to work at angles up to 25°.
Order-No.
24190 369R SZ13 5
369 Zoll C 0.05 1/16 5/64 3/32 7/64
369R Zoll 1/8 9/64 5/32 3/16 7/32
1/4 5/16 3/8
Wiha MagicRing ® hexagon L-key.
Securely holds hexagon bolts in place in any position.
N E W
N E W
SB 369R SZ13 Ball end hex L-key set in ProStar.
With MagicRing ® , chrome-plated, 13 pcs. Inch sizes.
Blister packed.
Order-No.
24850 SB 369R SZ13 5
MagicRing ®
MagicRing ®
MagicRing ®
MagicRing ®
MagicRing ®
MagicRing ®
MagicRing ®
MagicRing ®
