Velleman К8056 User Manual
Page 8
8
Construction
SK10 : 2p => RS232 input
SK11 : 2p => V Out 12V
SK12 : 2p
SK13 : 2p
SK14 : 2p
SK15 : 2p
SK16 : 2p
SK17 : 2p
SK18 : 2p
SK19 : 2p
Input 1 … 8
VDR1
VDR2
VDR3
VDR4
VDR5
VDR6
VDR7
VDR8
14. VDR’s
VDR300 (300VAC/385VDC)
VR1 : UA7805
Check the
orientation !
15. Voltage regulator
VR...
C5 : 1000µF
16. Electrolytic capacitor.
Watch the polarity !
C...
RY1
RY2
RY3
RY4 VR10V121C
RY5
RY6
RY7
RY8
17. Relays
IC1 : VK8056
programmed
Pic16F630 or eq.
18. IC. Watch the position of the
notch!
