Note : You can download software from our website www.velleman.be which
makes it very easy to control your relay card(s).
A. Operating modes:
The K8056 features 4 operating modes :
1. Set all outputs active / non-active
X
2. Eight toggle buttons
Y
3. Eight momentary buttons
Z
4. One button is reserved as 'emergency' function
[
Momentary : Hold the key to activate the output and release the key to
deactivate it.
Toggle : Operates according to the principal of a classic switch, i.e. press a key
once to activate and press again to deactivate.
Emergency function : Deactivate all the outputs on the same time.
B. Address selection:
1. Select the address of the relay card you want to control.
\
2. Confirm the selection by clicking the "show addr." button.
]
NOTE : Make sure that you have selected the correct serial port!
^
C. Changing address :
Choose the address you want to allocate to the relay card and confirm it by
clicking the "Chang addr." button.
_
21. DIAGNOSTIC / TEST SOFTWARE
Diagnostic / Test software
