Specifications:
• 433MHz operation
• LED function/mode indication
• Power supply: 3 AAA batteries (not included).
• Dimensions: 150 x 58 x 20mm (5.9" x 2.3" x 0.8")
Features:
Works together with the K8056 relay card.
8 addresses allow the use of multiple receivers.
'all clear'- function.
Toggle or momentary mode for each key.
Open-field range up to 50m.
Rubber keypad.
2
Features & specifications
LD1
LED3RL
R7 1K
R3 33K
SW1
1
SW2
2
SW9
SHIFT
SW4
4
SW6
5
SW8
6
SW5
7
SW7
8
SW3
3
GND
RA5/T1CKI/OSC1/CLKIN 2
RA3/MCLR/Vpp
4
RC5
5
RC4 6
RC3
7
RA4/T1G/OSC2/CLKOUT 3
RA0/CIN+/ICSPDAT 13
RA1/CIN-/ICSPCLK
12
RA2/COUT/T0CKI/INT 11
RC2 8
RC1 9
RC0
10
VDD
1
VSS
14
IC1
PIC16F630-I/P
GND
J2
J1
R4
33K
R5
33K
GND
+V +V
+V
C1
100n
GND +V
GND
Address selection
SW10
SHIFT
C5
100p
L2
COIL PCB 433
T1
MPSH10
R2
33K
R6
220
GND
L1
C
O
IL
1T
43
3 X1
SAW433
GND
C4
4p7
GND
C2
1p
C3
56p
GND
R1
47
Schematic diagram.
470
