- 16 -
Only push buttons connected to the Velbus via a push button interface or a control panel are appropriate for the procedure below.
Each command can accept up to 14 different push buttons. Memorize he unique address of the module.
The lamp will be switched off and the operation mode LED will blink very rapidly to indicate the learning mode. The LEDs of the
learned push buttons will also blink very rapidly.
You can add a specific push button by maintaining it pressed until the lamp lights up. When releasing the push button the lamp
will switch off and the push button indication LED will blink very rapidly as a confirmation. If this does not work then the maximum
amount of push buttons has been reached.
To delete a learned push button, maintain it pressed. When releasing the push button the indication LED will be turned off. You
can delete all learned push buttons for a specific control group by maintaining the manual control on the dimmer module pressed
until the lamp lights up. When releasing the manual control push button the lamp and the indication LEDs of all corresponding push
buttons will turn off.
LEARNING MODE
Address
Command
Address
Command
F1
OFF: Learning push buttons switching off the lamp
B1
UP: Learning push buttons increasing the lamp’s
intensity
E1
ON: Learning push buttons turning on the lamp to full
intensity
A1
DWN: Learning push buttons decreasing the lamp’s
intensity
D1
TGL: Learning push buttons turning on the lamp to
full intensity or turning the lamp off
91
ATM: Learning push buttons turning on the lamp to
a specific light intensity (atmosphere)
C1
DIM: Learning push buttons/sliders activating the set
mode on the module
81
ADM: Lamp’s light intensity for corresponding
atmosphere push buttons
