Velleman К8063 User Manual
Page 7
7
Construction
Mount the spacers onto the PCB with the 2 in-
cluded screws and install the digit display on the
solder side of the PCB. Pay attention to the posi-
tion of the decimal point, see figure 1.0.
Then turn the PCB around and place it into the housing with the display
towards the front, see figure 2.0.
13. Assembly
Fig 1.0
Fig 2.0
2nd digit
1st digit
