Velleman К8082 - Manual (Page 7)

7
(2) DISPLAY
S e tup:
Ve
lle m a n
: 1 m . ti m e r/ 1
o : 1 m . ti m e r/ 0
d: de
fa ul t
S : se
t co
d e
c: c o n t.
t: ti m e r
cw ccw 0 cw 1 ccw 0 cw 1 code: default
f
.
g
e
d
c
b
a
enc2 enc1 +5V
2 1 . g f e d c b a +5 V gn d P8082'1
R13
R12
R11
R10 R9
R8
R7
R6 DY1
SW2
1
Mount the components on the display PCB
R6 : 560 (5 - 6 - 1 - B)
R7 : 560 (5 - 6 - 1 - B)
R8 : 560 (5 - 6 - 1 - B)
R9 : 560 (5 - 6 - 1 - B)
R10 : 560 (5 - 6 - 1 - B)
R11 : 560 (5 - 6 - 1 - B)
R12 : 560 (5 - 6 - 1 - B)
R13 : 560 (5 - 6 - 1 - B)
1. Resistors
R... Pay attention to the position of the decimal point.
DY1
2. Display
SW2 : Rotary encoder
3. Digital potentiometer
Construction main PCB
