VMB8PBU – ed.1 | 8-channel pushbutton module
3
DESCRIPTION
With this pushbutton interface it is possible to connect up to 8 pushbuttons from any brand to your Velbus installation.
Optional LEDs for feedback and backlighting can easily be connected
CHARACTERISTICS
Use:
• Up to 8 pushbuttons connectable
• Can be used to connect any type of pushbutton to the Velbus (connection wires may not be extended)
LED indications:
• Possible to connect a LED over the pushbutton
o
VMBLDN: blue LEDs for NIKO
TM
pushbuttons
o
VMBLDAN: amber LEDs for NIKO
TM
pushbuttons
o
VMBLDB: blue LEDs for bticino
TM
pushbuttons from the Living®, Light® and Light-Tech® series
o
VMBLDAB: amber LEDs for bticino
TM
pushbuttons from the Living®, Light® and Light-Tech® series
• Backlighting of the buttons:
o
Switchable, on or off
o
Brightness
adjustable
• Feedback on the buttons
o
Switchable, on or off
o
Flashing mode on or off
• Presence of input voltage
• Sending or receiving data over the Velbus
Configuration:
• Only configurable via a Velbus pc interface (VMB1USB, VMB1RS or VMBRSUSB) and the Velbuslink software
• Software addressing (up to 250 addresses possible)
• Response time for each pushbutton adjustable between 0, 1, 2 or 3 seconds
• The behaviour op the pushbutton can be altered to a normally closed type
• Every pushbutton can be suppressed
• Configuration settings are preserved during power cuts
Power supply module:
• Required operating voltage: 12...18Vdc
• Consumption when idle: 16mA
• Maximum consumption (all LEDs on): 35mA
Dimensions:
• width x height x depth: 40x30x14mm
