Velleman К8092 User Manual
Page 7
7
RV1 : 1K
16. Trimmer
Construction
IC1 : VK8092
(programmed PIC12F629)
20. IC. Watch the
position of the notch!
RV...
C3 : 100µF / 25V
15. Electrolytic Capacitor.
Watch the polarity !
C...
RY1
RY...
17. Relay
SK1 : 2p 'power supply'
SK2 : 2p 'output relay'
18. Terminal block
LD3 : 3mm (red)
19. LED. Watch the polarity!
Mount LD3 if used with Velbus
VMB8PB.
IRX1 : 38KHz/600µs
(BRM-1040)
14. IR - demodulator
GND
+V
OUT
1
3
2
1 2 3
7
RV1 : 1K
16. Trimmer
Construction
IC1 : VK8092
(programmed PIC12F629)
20. IC. Watch the
position of the notch!
RV...
C3 : 100µF / 25V
15. Electrolytic Capacitor.
Watch the polarity !
C...
RY1
RY...
17. Relay
SK1 : 2p 'power supply'
SK2 : 2p 'output relay'
18. Terminal block
LD3 : 3mm (red)
19. LED. Watch the polarity!
Mount LD3 if used with Velbus
VMB8PB.
IRX1 : 38KHz/600µs
(BRM-1040)
14. IR - demodulator
GND
+V
OUT
1
3
2
1 2 3
