VMB8IR IR receiver module user manual – version 1

DESCRIPTION

This IR receiver module allows up to 40 remote commands. The first 8 channels also feature an indication LED.
Compatible transmitters are the universal remote controls from the Logitech Harmony series (Velbus codes can
be downloaded from the Logitech website).

CHARACTERISTICS

Use:

• IR remote control for your Velbus installation

• up to 40 channels

• 8 channels feature an indication LED

LED indications:

• status indication for the first 8 channels

• IR

reception

• power

voltage

present

• data reception and transfer over the Velbus

Control:

• 40 channels to be controlled through a universal remote control from the Logitech Harmony series

• local control for identification and/or addressing through the Velbuslink software

Configuration:

• only configurable via the Velbus PC interface (VMB1USB, VMB1RS or VMBRSUSB) and the Velbuslink

software

• addressing through software (up to 250 addresses)

• 32 out of the 40 channels reproduce the pushbutton functions from your Velbus installation

• adjustable reaction delay per channel between 0, 1, 2 and 3 seconds

• suppression possibility for every channel

• learned pushbuttons are saved in case of a power failure

• Logitech Harmony codes to be configured through the Logitech configuration software

IR receiver:

• IR modulation system: RECS80 with pulse position

• transmission/receiving range: ± 8m

Module power supply:

• required power voltage: 12...18VDC

• consumption in stand-by: 20mA

• max. consumption: 35mA

Dimensions:

• W x H x D: 22 x 46 x 43mm
