4 Main Interface
The main interface is divided into five sections:
1)
Measure controls (see section 5.1, p. 6)
2)
Measure info (see section 5.2, p. 6)
3)
Menu bar (see section 5.3, p. 7)
4)
Display area (see section 5.4, p. 8)
The following operations can be performed using the main interface:
• Perform a measurement
• Modify the setup using the
menu
• Save/Open/Export data, Save/Open config and Quit using the
menu
Display area
Menu bar
Measure controls
File
info
Measure
info
