Oracle Lighting SE109-LED User Manual
Interior step light, Ste p lig ht
inTERiOR STEP light
270
www.oraclelighting.com • tel: 1-877-375-5555 • FaX: 1-877-375-3333
Ste
p
Lig
ht
Diffuse Glass Lens
w/White Trim
Housing Included
Angled Louvers
w/White Trim
Housing Included
Se106-leD-wh
Se107-leD-wh
:: FiT in hAnDy BOX WhiCh iS 1-7/8” DEEP, 2” W X 4” h
:: FiT in SWiTCh BOX WhiCh iS 1-7/8” DEEP, 2” W X 4” h
Se109-leD-wh
Se108-leD-wh
::
0.4 W (0.05W X 8)
::
120V input
::
For use indoors in insulated (IC) and Non- insulated
(NON-IC) areas.
::
For damp location only.
::
Conforms to UL standard 1598.
::
Available in 2700K Warm White (WW) or Amber (AM)
SERiES
Se106-leD-ww
Se106-leD-am
Se107-leD-ww
Se107-leD-am
Se108-leD-ww
Se108-leD-am
Se109-leD-ww
Se109-leD-am
wh- white
BZ- BronZ
Sn- Satin nicKel
FiniSh
Ordering Example: SE106-lED-WW-Wh
4-1/2”
2-3/4”
3”
Catalog Number
SE109-LED
Project Name
Type
SE109-LED
