169 www.oraclelighting.com • tel: 1-877-375-5555 • FaX: 1-877-375-3333
T8/T5 LAMPS SURFACE OR SUSPENDED MOUNT
(2 lamp/32W/T8)
(2 lamps/28W/T5)
(2 lamps/54W/T5HO)
4’ FIxTURE
2-32-T8
2-28-T5
2-54-T5HO
BALLAST CONFIGURATION & CODE
32W/T8 28W/T5 54W/T5HO DESCRIPTION
(Blank) - - Electronic Instant Start
EPS (Blank) (Blank) Electronic Program Start
ADV-7 - ADV-7 Advance Mark-7 1
ADV-10 - ADV-10 Advance Mark-10 1
- ADV-OPT - Advance Optanium 1
ADV-ESS - - Advance Essential 1
ADV-ROVR - ADV-ROVR Advance Rover 1
LUT-EHD LUT-EHD LUT-EHD Lutron Ecosystem H-Series 1
LUT-2W - - Lutron Tu-Wire 1
LUT-EC5 LUT-EC5 - Lutron Ecosystem 1
LUT-EC3 LUT-EC3 LUT-EC3 Lutron Eco-10 1
LUT-TVE - - Lutron Tve 1
LUT-H3D LUT-H3D LUT-H3D Lutron Hi-Lume 3D 1
- - LUT-ECD Lutron Ecosystem (347V Only) 1
1- Voltage must be specified for dimming ballast.
SERIES
OB2DI-
Oracle Surface
Mount
Direct/Indirect
With Perforated
Shield
OB3DI-
Oracle Surface
Mount
Direct/Indirect
With Clear
Acrylic Shield
WATTAGE
-1 Ballast
-2 Ballasts ( Blank)
2
# OF BALLAST
(Blank)
HBF
LBF
BALLAST FACTOR VOLTAGE 1
- Normal BF
- High BF
- Low BF 4 - 4’
FIxTURE SIzE
OTHER OPTIONS
INMS - Motion Sensor
OCGSS - Cable Gripper Suspension Kit
USA - Made in America Compliance
WIRING OPTIONS
C3 - 6’ 3-wire Flex Cable (Single Circuit)
C4 - 6’ 4-wire Flex Cable (Double Circuit)
FBF - Internal Fast Blow Fuse
SBF - Internal Slow-Blow Fuse
RIS - Radio Interference Suppressor
EMERGENCY BATTERY PACK OPTIONS (L. = LUMENS)
ORDER CODE DESCRIPTION
EMG-T8-Bx-450 Up to 450 L. for T8 or Bx
EMG-T8-Bx-600 Up to 600 L. for T8 or Bx
EMG-T8-Bx-700 Up to 700 L. for T8 or Bx
EMG-T8-Bx-1400 Up to 1400 L. for T8 or Bx
EMG-T5-520 Up to 520 L. for T5
EMG-T5-T5HO-700 Up to 700 L. for T5 or T5HO
EMG-T5-T5HO-1300 Up to 1300 L. for T5 or T5HO
EMG-T8-Bx-T5-T5HO-3200 Up to 3200 L. for T8, Bx, T5 or T5HO
EMG-SD-T8-Bx-T5-T5HO-1400 Self-Diagnostic 1400 L. for T8, Bx, T5 or T5HO
EMG-ICE-T8-Bx-T5-T5HO-1400 ICE Pack 1400 L. for T8, Bx, T5 or T5HO
( Blank)
120
277
347
- MVOLT (120/277)
4’
Flu
ore
sc
en
t D
ire
ct
/in
dire
ct
l
um
in
air
Ordering Information
eXamPle: 4-oB2Di-2-28-t5
- White
- White/ Slotted
- Silver
REFLECTOR
(Blank)
OB2DI-WSU
OB2DI-SR
SPECIFICATION GUIDE:
DESCRiPTiOn PART# DimEnSiOnS
oB2Di-wSU
oB2Di-Sr
w=10-3/8, h=5-3/4, l=48
w=10-3/8, h=5-3/4, l=48
white Slotted reflector
Silver reflector
liSting:
:: Fixture and ballast UL Listed
:: Electronic ballast thermally protected class P, NPF, Non PCB.
T8/T5
OB2
SUSPENSION SYSTEM
Refer to page 150
