CW-11 Indicator
2.8 Initial Setup (Cont.)
2.8.3 Load Cell Capacity Information
Review the specifications of the scale base to be used with the Indicator. Make sure the settings you select in the
indicator are compatible with the scale base. Below is a Load Cell Scale Capacity (lb or kg) table. Use this table
to determine the settings of the Indicator based on the capacity and resolution of the scale base.
LOAD CELL SCALE CAPACITIES (LB OR Kg)
Grad
1000d 1200d 1500d 2000d 2500d 3000d 4000d 5000d 6000d 7500d 10000d 20000d 12500d 15000d
0.001 - - - 2 - 3 - 5 - - 10 20 - 15
0.002 - - - 4 - 6 - 10 - 15 20 40 25 30
0.005 5 - - 10 - 15 20 20 30 - 50 100 - 75
0.01 10 - - 20 25 30 40 50 60 75 100 200 - 150
0.02 20 - 30 40 50 60 - 100 120 150 200 400 250 300
0.05 50 60 75 100 - 150 200 250 300 - 500 1000 - 750
0.1 100 120 150 200 250 300 400 500 600 750 1000 2000 - 1500
0.2 200 - 300 400 500 600 - 1000 - 1500 2000 - 2500 3000
0.5 500 600 750 1000 - 1500 2000 2500 3000 - 5000 10000 - 7500
1 1000 1200 1500 2000 2500 3000 - 5000 - 7500 10000 20000 - -
2 2000 - 3000 - 5000 - - 10000 - - 20000 - - -
5 5000 - 7500 10000 - - 20000 - - - - - - -
