Defender Series Base EN-7
TABLE 2.9 SPECIFICATIONS
MODEL D100RL D100RX D100RV D150RL D150RX
Capacity 100 kg / 250 lb 100 kg / 250 lb 100 kg / 250 lb 150 kg / 300 lb 150 kg / 300 lb
Approved Resolution NTEP: 5000d NTEP: 5000d NTEP: 5000d OIML: 3000e OIML: 3000e
Safe Overload Capacity 150% of capacity
Pan Dimensions 400 x 500 mm
15.7 x 19.7 in
500 x 650 mm
19.7 x 25.6 in
600 x 800 mm
23.6 x 31.5 in
400 x 500 mm
15.7 x 19.7 in
500 x 650 mm
19.7 x 25.6 in
Base Construction Stainless Steel platform with painted steel frame and rubber leveling feet
Repeatability (std. deviation) 1d
Linearity ±1d
Load Cell Capacity
250 kg
Load Cell Cable 2.5 m L x 6-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Load Cell Protection IP65
Net Weight 19.4 kg / 43 lb 22.3 kg / 49 lb 36.8 kg / 81 lb 19.4 kg / 43 lb 22.3 kg / 49 lb
Shipping Weight 22.3 kg / 49 lb 27.8 kg / 61 lb 63.2 kg / 139 lb 22.3 kg / 49 lb 27.8 kg / 61 lb
TABLE 2.10 SPECIFICATIONS
MODEL D150RV D250RX D250RV D300RX D300RV
Capacity 150 kg / 300 lb 250 kg / 500 lb 250 kg / 500 lb 300 kg / 600 lb 300 kg / 600 lb
Approved Resolution OIML: 3000e NTEP: 5000d NTEP: 5000d OIML: 3000e OIML: 3000e
Safe Overload Capacity 150% of capacity
Pan Dimensions 600 x 800 mm
23.6 x 31.5 in
500 x 650 mm
19.7 x 25.6 in
600 x 800 mm
23.6 x 31.5 in
500 x 650 mm
19.7 x 25.6 in 600 x 800 mm
23.6 x 31.5 in
Base Construction Stainless Steel platform with painted steel frame and rubber leveling feet
Repeatability (std. deviation) 1d
Linearity ±1d
Load Cell Capacity
250 kg 500 kg
Load Cell Cable 2.5 m L x 6-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Load Cell Protection IP65
Net Weight 36.8 kg / 81 lb 22.3 kg / 49 lb 36.8 kg / 81 lb 22.3 kg / 49 lb 36.8 kg / 81 lb
Shipping Weight 63.2 kg / 139 lb 27.8 kg / 61 lb 63.2 kg / 139 lb 27.8 kg / 61 lb 63.2 kg / 139 lb
