Defender Series Base EN-3
TECHNICAL DATA
Technical Specifications
The technical data is valid under the following ambient conditions:
Ambient temperature: -10ºC to +40 ºC
Relative humidity: 10% to 90% relative humidity, non-condensing
Height above sea level: Up to 2,000m
Operability is assured at ambient temperature -10ºC to +40 ºC
Note: not all models may be available in your area. Check with your local Ohaus representative.
TABLE 2.1 SPECIFICATIONS
MODEL D15HR D30HR D60HR
Capacity 15 kg / 30 lb 30 kg / 60 lb 60 kg / 150 lb
Approved Resolution OIML: 3000e, NTEP: 3000d
Safe Overload Capacity 150% of capacity
Pan Dimensions 305 x 355 mm / 12 x 14 in
Base Construction Stainless Steel platform with painted steel frame and rubber leveling feet
Repeatability (std. deviation) 1d
Linearity ±1d
Load Cell Capacity
30 kg 50 kg 100 kg
Load Cell Cable 2 m L x 6-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Load Cell Protection IP67
Net Weight 9 kg / 19.8 lb
Shipping Weight 10.9 kg / 24 lb
TABLE 2.2. SPECIFICATIONS
MODEL D60HL D100HL D150HX D300HX
Capacity 60 kg / 100 lb 100 kg / 250 lb 150 kg / 300 lb 300 kg / 600 lb
Approved Resolution OIML: 3000e,
NTEP: 3000d
OIML: 3000e,
NTEP: 2500d
OIML: 3000e,
NTEP: 3000d
Safe Overload Capacity 150% of capacity
Pan Dimensions 400 x 500 mm / 15.7 x 19.7 in 420 x 550 mm / 16.5 x 21.6 in
Base Construction Stainless Steel platform with painted steel frame and rubber leveling feet
Repeatability (std. deviation) 1d
Linearity ±1d
Load Cell Capacity
100 kg 150 kg 300 kg 500 kg
Load Cell Cable 2 m L x 6-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Load Cell Protection IP67
Net Weight 19.1 kg / 42.1 lb 24.5 kg
Shipping Weight 22 kg / 48.5 lb 27.1 kg / 59.7 lb
