EN-6 Defender Series Base
TABLE 2.7 SPECIFICATIONS
MODEL D5RS D6RS D10RS D15RS D25RR D30RR
Capacity 5 kg / 10 lb 6 kg / 15 lb 10 kg / 25 lb 15 kg / 30 lb 25 kg / 50 lb 30 kg / 60 lb
Approved Resolution NTEP: 5000d OIML: 3000e NTEP: 5000d OIML: 3000e NTEP: 5000d OIML: 3000e
Safe Overload Capacity 150% of capacity
Pan Dimensions 240 x 300 mm /
9.4 x 11.8 in
300 x 400 mm /
11.8 x 15.7 in
Base Construction Stainless Steel platform with painted steel frame and rubber leveling feet
Repeatability (std. deviation) 1d
Linearity ±1d
Load Cell Capacity
11 kg 22 kg 50 kg
Load Cell Cable 1 m L x 6-wire 2 m L x 6-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Load Cell Protection IP65
Net Weight 5.9 kg / 13 lb 9.9 kg / 22 lb
Shipping Weight 8.1 kg / 18 lb 12 kg / 26.5 lb
TABLE 2.8 SPECIFICATIONS
MODEL D50RR D50RL D50RX D60RR D60RL D60RX
Capacity 50 kg / 100 lb 50 kg / 100 lb 50 kg / 100 lb 60 kg / 150 lb 60 kg / 150 lb 60 kg / 150 lb
Approved Resolution NTEP: 5000d NTEP: 5000d NTEP: 5000d OIML: 3000e OIML: 3000e OIML: 3000e
Safe Overload Capacity 150% of capacity
Pan Dimensions 300 x 400 mm
11.8 x 15.7 in
400 x 500 mm
15.7 x 19.7 in
500 x 650 mm
19.7 x 25.6 in
300 x 400 mm
11.8 x 15.7 in
400 x 500 mm
15.7 x 19.7 in
500 x 650 mm
19.7 x 25.6 in
Base Construction Stainless Steel platform with painted steel frame and rubber leveling feet
Repeatability (std.
deviation) 1d
Linearity ±1d
Load Cell Capacity
100 kg
Load Cell Cable 2 m L x 6-wire 2.5 m L x 6-wire 2 m L x 6-wire 2.5 m L x 6-wire
Load Cell Type 350 Ohm, aluminum, single point
Load Cell Excitation 5-15V DC/AC
Load Cell Rated Output 2mV/V
Load Cell Protection IP65
Net Weight 9.9 kg / 22 lb 19.4kg / 43lb 22.3 kg / 49 lb 9.9 kg / 22 lb 19.4 kg / 43 lb 22.3 kg / 49 lb
Shipping Weight 12 kg / 26.5 lb 22.3kg / 49lb 27.8 kg / 61 lb 12 kg / 26.5 lb 22.3 kg / 49 lb 27.8 kg / 61 lb
