8
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
MODEL MODEL MODEL MODEL MODEL LB30 LB30 LB30 LB30 LB30 LB60 LB60 LB60 LB60 LB60 PL100 PL100 PL100 PL100 PL100 PL150 PL150 PL150 PL150 PL150
Capacity (lb/kg) 30/13.5 60/27.2 100/45.3 150/68
Readability (lb/kg)** 0.01/0.005 0.02/0.01 0.02/0.01 0.05/0.05
Platform size (in/cm) 12 x 12/30.5 x 30.5 18 x 18/45.7 x 45.7
Safe overload* 150%
Maximum overload* 300%
Linearity* 0.02%
Repeatabilty* 0.01%
Shift accuracy* 0.025%
(50% Capacity/50% Distance)3 seconds
Load cell excitation (VDC) 5 to 15
Output impedance (ohms) 350
Output at rated load (mV/V) 2
Temperature range 32° to 104°F/0° to 40° C (Non type approved)
50° to 104°F/10° to 40° C (Type approved)
Net weight (lb/kg) 12/5.5 27.2/12.4
Shipping weight (lb/kg) 14/6.4 33/15
NIST HB44 Class III
NIST/NTEP n
max
= 3000 n
max
=5000 n
max
= 3000
NTEP Certificate of Conformance
No. 88-203 No. 88-228
Consumer and Corporate Weights and Measures Act and Regulations General
Class Affairs Canada Notice of Approval No. S.WA-
4467
* Specifications are given as a percent of the rated load.
** In Legal for Trade applications, readability is limited to Capacity/n
max
