6
Leveling the Scale Base Leveling the Scale Base Leveling the Scale Base Leveling the Scale Base Leveling the Scale Base
1. Place the Scale Base in the intended use location on a stable, level surface.
2. Remove the stainless steel Platform from the top of the Scale Base to expose
the circular Spirt Level mounted in the top of the sub-platform.
3. If the bubble is not centered in the scribed circle of the Spirit Level, loosen
the Locking Nuts and adjust the Leveling Feet until the bubble is centered.
4. Tighten the Locking Nuts and replace the Platform.
SPIRIT LEVEL
INDICATOR
Calibration Calibration Calibration Calibration Calibration
Refer to the Indicator Instruction Manual for the system calibration procedure.
Scale Base (Platform Removed)
